Optimizely Search / Episerver Find: Inspect the underlying query
Optimizely Search & Navigation (a.k.a. EPiServer Find) ia a powerful engine but, as being a black box, it might be difficult to diagnose its behavior when things go wrong. This article describes how to make a deep dive into the search engine and get the insights about the underlying query.
EPiServer Find relies on the Elasticsearch engine. The Find client constructs the query that is being sent to Elasticsearch server and then Episerver process the response. Exact queries that are being sent can be catch in the following ways:
- WireShark: rather advanced method
- Set-up proxy server (e.g. Fiddler) and catch all the traffic: useful to analyze all the traffic to Elasticsearch1
- Debug internals of the Find client: the most convenient way, but it requires knowledge where to catch
In this article I will focus on the last method.
How to inspect the query?
Basically, you might want to set a breakpoint in the EPiServer.Find.Api class in the place where the request is constructed and is being serialized to JSON. In the current version of the Find client, it is under:
SearchCommand<TResult>→Execute→string str = this.CommandContext.Serializer...
Usually, I set the non-suspending execution breakpoint in this place and log it to the console, so I can see the query in the debug output.
Below is the example of the query generated using the Foundation project (source code)
Please expand to see more details:
Request
{
"from": 0,
"size": 10,
"query": {
"filtered": {
"query": {
"filtered": {
"query": {
"custom_filters_score": {
"query": {
"filtered": {
"query": {
"query_string": {
"query": "boot",
"analyzer": "synonym"
}
},
"filter": {
"and": [
{
"term": {
"Language.Name$$string": "en"
}
},
{
"or": [
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Commerce.Catalog.ContentTypes.EntryContentBase"
}
}
}
},
{
"term": {
"Markets.Value$$string": "US"
}
}
]
}
]
}
}
},
"filters": [
{
"filter": {
"term": {
"Boost$$number": 2
}
},
"boost": 1.05
},
{
"filter": {
"term": {
"Boost$$number": 3
}
},
"boost": 1.1
},
{
"filter": {
"term": {
"Boost$$number": 4
}
},
"boost": 1.15
},
{
"filter": {
"term": {
"Boost$$number": 5
}
},
"boost": 1.2
}
],
"score_mode": "total"
}
},
"filter": {
"and": [
{
"term": {
"Bury$$bool": false
}
},
{
"or": [
{
"and": [
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Core.ILocalizable"
}
}
}
},
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Core.IVersionable"
}
}
}
}
]
},
{
"and": [
{
"term": {
"___types": "EPiServer.Core.ILocalizable"
}
},
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Core.IVersionable"
}
}
}
},
{
"term": {
"Language.Name$$string.lowercase": "en"
}
}
]
},
{
"and": [
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Core.ILocalizable"
}
}
}
},
{
"term": {
"___types": "EPiServer.Core.IVersionable"
}
},
{
"and": [
{
"term": {
"Status": 4
}
},
{
"range": {
"StartPublishedNormalized$$date": {
"from": "0001-01-01T00:00:00Z",
"to": "now",
"include_lower": true,
"include_upper": true
}
}
},
{
"or": [
{
"not": {
"filter": {
"exists": {
"field": "StopPublish$$date"
}
}
}
},
{
"range": {
"StopPublish$$date": {
"from": "now",
"to": "9999-12-31T22:59:59.9999999Z",
"include_lower": false,
"include_upper": true
}
}
}
]
}
]
}
]
},
{
"and": [
{
"or": [
{
"not": {
"filter": {
"exists": {
"field": "PublishedInLanguage.en.StopPublish$$date"
}
}
}
},
{
"range": {
"PublishedInLanguage.en.StopPublish$$date": {
"from": "now",
"to": "9999-12-31T22:59:59.9999999Z",
"include_lower": false,
"include_upper": true
}
}
}
]
},
{
"range": {
"PublishedInLanguage.en.StartPublish$$date": {
"from": "0001-01-01T00:00:00Z",
"to": "now",
"include_lower": true,
"include_upper": true
}
}
}
]
},
{
"and": [
{
"or": [
{
"not": {
"filter": {
"exists": {
"field": "PublishedInLanguage.en.StopPublish$$date"
}
}
}
},
{
"range": {
"PublishedInLanguage.en.StopPublish$$date": {
"from": "now",
"to": "9999-12-31T22:59:59.9999999Z",
"include_lower": false,
"include_upper": true
}
}
}
]
},
{
"range": {
"PublishedInLanguage.en.StartPublish$$date": {
"from": "0001-01-01T00:00:00Z",
"to": "now",
"include_lower": true,
"include_upper": true
}
}
}
]
}
]
},
{
"and": [
{
"or": [
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Commerce.Catalog.ContentTypes.EntryContentBase"
}
}
}
},
{
"term": {
"Markets.Value$$string": "US"
}
}
]
},
{
"or": [
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Core.IContent"
}
}
}
},
{
"term": {
"IsDeleted$$bool": false
}
}
]
},
{
"or": [
{
"and": [
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Core.ILocalizable"
}
}
}
},
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Core.IVersionable"
}
}
}
}
]
},
{
"and": [
{
"term": {
"___types": "EPiServer.Core.ILocalizable"
}
},
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Core.IVersionable"
}
}
}
},
{
"term": {
"Language.Name$$string.lowercase": "en"
}
}
]
},
{
"and": [
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Core.ILocalizable"
}
}
}
},
{
"term": {
"___types": "EPiServer.Core.IVersionable"
}
},
{
"and": [
{
"term": {
"Status": 4
}
},
{
"range": {
"StartPublishedNormalized$$date": {
"from": "0001-01-01T00:00:00Z",
"to": "now",
"include_lower": true,
"include_upper": true
}
}
},
{
"or": [
{
"not": {
"filter": {
"exists": {
"field": "StopPublish$$date"
}
}
}
},
{
"range": {
"StopPublish$$date": {
"from": "now",
"to": "9999-12-31T22:59:59.9999999Z",
"include_lower": false,
"include_upper": true
}
}
}
]
}
]
}
]
},
{
"and": [
{
"or": [
{
"not": {
"filter": {
"exists": {
"field": "PublishedInLanguage.en.StopPublish$$date"
}
}
}
},
{
"range": {
"PublishedInLanguage.en.StopPublish$$date": {
"from": "now",
"to": "9999-12-31T22:59:59.9999999Z",
"include_lower": false,
"include_upper": true
}
}
}
]
},
{
"range": {
"PublishedInLanguage.en.StartPublish$$date": {
"from": "0001-01-01T00:00:00Z",
"to": "now",
"include_lower": true,
"include_upper": true
}
}
}
]
},
{
"and": [
{
"or": [
{
"not": {
"filter": {
"exists": {
"field": "PublishedInLanguage.en.StopPublish$$date"
}
}
}
},
{
"range": {
"PublishedInLanguage.en.StopPublish$$date": {
"from": "now",
"to": "9999-12-31T22:59:59.9999999Z",
"include_lower": false,
"include_upper": true
}
}
}
]
},
{
"range": {
"PublishedInLanguage.en.StartPublish$$date": {
"from": "0001-01-01T00:00:00Z",
"to": "now",
"include_lower": true,
"include_upper": true
}
}
}
]
}
]
},
{
"or": [
{
"not": {
"filter": {
"term": {
"___types": "EPiServer.Security.IContentSecurable"
}
}
}
},
{
"term": {
"UsersWithReadAccess$$string.lowercase": "admin@example.com"
}
},
{
"terms": {
"RolesWithReadAccess$$string": [
"Administrators",
"WebAdmins",
"Everyone",
"Authenticated",
"CommerceAdmins",
"CmsAdmins",
"VisitorGroupAdmins",
"GoogleAnalyticsAdministrators"
]
}
}
]
}
]
},
{
"term": {
"___types": "EPiServer.Core.IContent"
}
}
]
}
}
},
"filter": {
"term": {
"___types": "EPiServer.Commerce.Catalog.ContentTypes.EntryContentBase"
}
}
}
},
"sort": [
{
"_score": {}
}
],
"fields": [
"___types",
"ContentLink.ID$$number",
"ContentLink.ProviderName$$string",
"Language.Name$$string"
]
}
Request needs to be sent to the Elasticsearch server with POST verb. The URL is constructed basing on your index, i.e.:
https://SERVICE.find.episerver.net/INDEXID/INDEXNAME/_search
For example:
https://demo42.find.episerver.net/XSAfcsdfvs214fsa1zxwg/myindex/_search
Request seems to be self-explanatory — it's just an expression used for the search. All the query details are referenced in the official docs (see links at the end of the article).
The response from the above is as follows:
Response
{
"took": 4,
"timed_out": false,
"_shards": {
"total": 6,
"successful": 6,
"failed": 0
},
"hits": {
"total": 3,
"max_score": 0.6464435,
"hits": [
{
"_index": "myindex-en",
"_type": "Foundation_Features_CatalogContent_Product_GenericProduct",
"_id": "CatalogContent_fbe1fb54-d02e-493c-a64d-025217a34de3_en",
"_score": 0.6464435,
"_source": {
"ContentLink": {}
},
"fields": {
"___types": [
"Foundation.Features.CatalogContent.Product.GenericProduct_DynamicProxy",
"Foundation.Features.CatalogContent.Product.GenericProduct",
"EPiServer.Commerce.Catalog.ContentTypes.ProductContent",
"EPiServer.Commerce.Catalog.ContentTypes.EntryContentBase",
"EPiServer.Commerce.Catalog.ContentTypes.CatalogContentBase",
"EPiServer.Core.ContentData",
"System.Object",
"EPiServer.Core.IContentData",
"EPiServer.Core.IInitializableContent",
"EPiServer.Core.IModifiedTrackable",
"EPiServer.Data.Entity.IReadOnly",
"EPiServer.Data.Entity.IReadOnly`1[[EPiServer.Commerce.Catalog.ContentTypes.CatalogContentBase, EPiServer.Business.Commerce, Version=14.15.1.0, Culture=neutral, PublicKeyToken=8fe83dea738b45b7]]",
"EPiServer.Core.IContent",
"EPiServer.Core.ILocalizable",
"EPiServer.Core.ILocale",
"EPiServer.Core.IVersionable",
"EPiServer.Web.Routing.IRoutable",
"EPiServer.Security.ISecurable",
"EPiServer.Commerce.Catalog.ContentTypes.IMetaClass",
"EPiServer.Commerce.Catalog.ContentTypes.ISearchEngineInformation",
"EPiServer.Core.IChangeTrackable",
"EPiServer.Commerce.Catalog.ContentTypes.ICategorizable",
"EPiServer.Commerce.Catalog.ContentTypes.IAssociating",
"EPiServer.Commerce.Catalog.ContentTypes.IAssetContainer",
"EPiServer.Commerce.Catalog.ContentTypes.IVariantContainer",
"Foundation.Features.CatalogContent.IProductRecommendations",
"Foundation.Features.Shared.IFoundationContent"
],
"Language.Name$$string": "en",
"ContentLink.ProviderName$$string": "CatalogContent",
"ContentLink.ID$$number": 49
}
},
{
"_index": "myindex-en",
"_type": "Foundation_Features_CatalogContent_Product_GenericProduct",
"_id": "CatalogContent_b2fd5c96-8042-4da7-8196-177721597676_en",
"_score": 0.5227358,
"_source": {
"ContentLink": {}
},
"fields": {
"___types": [
"Foundation.Features.CatalogContent.Product.GenericProduct_DynamicProxy",
"Foundation.Features.CatalogContent.Product.GenericProduct",
"EPiServer.Commerce.Catalog.ContentTypes.ProductContent",
"EPiServer.Commerce.Catalog.ContentTypes.EntryContentBase",
"EPiServer.Commerce.Catalog.ContentTypes.CatalogContentBase",
"EPiServer.Core.ContentData",
"System.Object",
"EPiServer.Core.IContentData",
"EPiServer.Core.IInitializableContent",
"EPiServer.Core.IModifiedTrackable",
"EPiServer.Data.Entity.IReadOnly",
"EPiServer.Data.Entity.IReadOnly`1[[EPiServer.Commerce.Catalog.ContentTypes.CatalogContentBase, EPiServer.Business.Commerce, Version=14.15.1.0, Culture=neutral, PublicKeyToken=8fe83dea738b45b7]]",
"EPiServer.Core.IContent",
"EPiServer.Core.ILocalizable",
"EPiServer.Core.ILocale",
"EPiServer.Core.IVersionable",
"EPiServer.Web.Routing.IRoutable",
"EPiServer.Security.ISecurable",
"EPiServer.Commerce.Catalog.ContentTypes.IMetaClass",
"EPiServer.Commerce.Catalog.ContentTypes.ISearchEngineInformation",
"EPiServer.Core.IChangeTrackable",
"EPiServer.Commerce.Catalog.ContentTypes.ICategorizable",
"EPiServer.Commerce.Catalog.ContentTypes.IAssociating",
"EPiServer.Commerce.Catalog.ContentTypes.IAssetContainer",
"EPiServer.Commerce.Catalog.ContentTypes.IVariantContainer",
"Foundation.Features.CatalogContent.IProductRecommendations",
"Foundation.Features.Shared.IFoundationContent"
],
"Language.Name$$string": "en",
"ContentLink.ProviderName$$string": "CatalogContent",
"ContentLink.ID$$number": 36
}
},
{
"_index": "myindex-en",
"_type": "Foundation_Features_CatalogContent_Product_GenericProduct",
"_id": "CatalogContent_873cfa45-a12d-45c5-a8c0-2104bb913b0f_en",
"_score": 0.27660578,
"_source": {
"ContentLink": {}
},
"fields": {
"___types": [
"Foundation.Features.CatalogContent.Product.GenericProduct_DynamicProxy",
"Foundation.Features.CatalogContent.Product.GenericProduct",
"EPiServer.Commerce.Catalog.ContentTypes.ProductContent",
"EPiServer.Commerce.Catalog.ContentTypes.EntryContentBase",
"EPiServer.Commerce.Catalog.ContentTypes.CatalogContentBase",
"EPiServer.Core.ContentData",
"System.Object",
"EPiServer.Core.IContentData",
"EPiServer.Core.IInitializableContent",
"EPiServer.Core.IModifiedTrackable",
"EPiServer.Data.Entity.IReadOnly",
"EPiServer.Data.Entity.IReadOnly`1[[EPiServer.Commerce.Catalog.ContentTypes.CatalogContentBase, EPiServer.Business.Commerce, Version=14.15.1.0, Culture=neutral, PublicKeyToken=8fe83dea738b45b7]]",
"EPiServer.Core.IContent",
"EPiServer.Core.ILocalizable",
"EPiServer.Core.ILocale",
"EPiServer.Core.IVersionable",
"EPiServer.Web.Routing.IRoutable",
"EPiServer.Security.ISecurable",
"EPiServer.Commerce.Catalog.ContentTypes.IMetaClass",
"EPiServer.Commerce.Catalog.ContentTypes.ISearchEngineInformation",
"EPiServer.Core.IChangeTrackable",
"EPiServer.Commerce.Catalog.ContentTypes.ICategorizable",
"EPiServer.Commerce.Catalog.ContentTypes.IAssociating",
"EPiServer.Commerce.Catalog.ContentTypes.IAssetContainer",
"EPiServer.Commerce.Catalog.ContentTypes.IVariantContainer",
"Foundation.Features.CatalogContent.IProductRecommendations",
"Foundation.Features.Shared.IFoundationContent"
],
"Language.Name$$string": "en",
"ContentLink.ProviderName$$string": "CatalogContent",
"ContentLink.ID$$number": 38
}
}
]
}
}
The response seems to be less-readable for human beings. For the ease of reading, you might manipulate the request a little bit. Usually, I'm changing what's being returned (the fields node).
Instead of:
...
"fields": [
"___types",
"ContentLink.ID$$number",
"ContentLink.ProviderName$$string",
"Language.Name$$string"
]
...I'm using:
...
"fields": [
"ContentLink.ID$$number",
"Code$$string",
"Name$$string"
]
...so the response is less cluttered and more human-readable (we can see Content ID, code and name):
{
"took": 6,
"timed_out": false,
"_shards": {
"total": 6,
"successful": 6,
"failed": 0
},
"hits": {
"total": 3,
"max_score": 0.6464435,
"hits": [
{
"_index": "myindex-en",
"_type": "Foundation_Features_CatalogContent_Product_GenericProduct",
"_id": "CatalogContent_fbe1fb54-d02e-493c-a64d-025217a34de3_en",
"_score": 0.6464435,
"_source": {
"ContentLink": {}
},
"fields": {
"Name$$string": "JODHPUR BOOT",
"ContentLink.ID$$number": 49,
"Code$$string": "P-39813617"
}
},
{
"_index": "myindex-en",
"_type": "Foundation_Features_CatalogContent_Product_GenericProduct",
"_id": "CatalogContent_b2fd5c96-8042-4da7-8196-177721597676_en",
"_score": 0.5669189,
"_source": {
"ContentLink": {}
},
"fields": {
"Name$$string": "JADE HIGH BOOT",
"ContentLink.ID$$number": 36,
"Code$$string": "P-27312001"
}
},
{
"_index": "myindex-en",
"_type": "Foundation_Features_CatalogContent_Product_GenericProduct",
"_id": "CatalogContent_873cfa45-a12d-45c5-a8c0-2104bb913b0f_en",
"_score": 0.2999853,
"_source": {
"ContentLink": {}
},
"fields": {
"Name$$string": "CLARA SHORT BOOT",
"ContentLink.ID$$number": 38,
"Code$$string": "P-27312186"
}
}
]
}
}
Basing on the RAW query, you may manipulate it and adjust to your needs. You can also remove/update expression parts to see which part of the query is responsible for the results. I've found this method very effective as results are immediate.
The query analysis is also needed for building custom search queries (wildcard, fuzziness, proximity, boosting terms, etc.) and invoke them from a code.
Please note that there are other queries running in other places than the SearchCommand.
Links
Footnotes
Check out the Charles Proxy article. ↩
